Side Rail
Side Rail features a self-flashing J-Channel that aids in easy panel skin installation and leaves a professional look.
Double Couple
H Rail
Seal out weather conditions with the Double Couple, as you eliminate the gap that naturally forms at the connection point of two door panel edges.
Steel Girt
Durable door frame support Designed for ideal horizontal support on sliding door frames is optimal for door frame construction and support.
Bottom Rail
The Bottom Rail can be used with a continuous guide rail or stay roller to provide optimal wind resistance for the Sliding Door System.
Bigg Frame
Bottom Rail
Designed to accommodate a continuous guide rail, the Bigg Frame Bottom Rail delivers increased wind resistance and diminished sliding door sway during use.
Bigg Frame
Side Rail
Designed specifically for larger door panels, Bigg Frame Side Rails offer self-flashing J-channels to enclose steel door skins for a trouble-free hold and easy installation.
Bigg Frame
Double H Rail
Larger sliding doors demand strong connections to keep out the elements - and the Bigg Frame Double H Couple handles the job with greater stability than standard H-rails.
Keyhole Track
CannonBall's Keyhole track offers versatility, strength and ease of use. This adaptable track style can be used with any sliding door variety or bracket type - and installs with a simple connection of brackets into keyholes before mounting.
Stay Guide
Best used with the Kwik Frame or Bigg Frame Sliding Door System, reduces the amount of door sway, helps prevent wind damage and provides easier door operation. Stay Guide lengths should measure 60% of the door panel width.
Cannonball Trollies
Delrin wheels for doors up to 600 lbs per pair.
CannonBall:HNP Round Track Trolleys feature roller bearings for maximum longevity and ease of operation. Round Track Trolleys are available with pendant bolt.
Purchase
Double Track Bracket
• For double sliding doors
• Requires standard track bracket in addition for track cover
Purchase
Center Snugger
The original Door Snugger from CannonBall:HNP. The chains sliding down the diverging rods draws the verticals closer together both adding strength against wind damage and helps to eliminate door rattle. Can be used with either wood or metal horizontals.
Purchase
Cannonball Keeper Stopper
Stops and holds door in either open or closed position.
The end with right angle projects beyond jamb and engages the aluminum side rail of sliding barn doors.
Purchase
Offset Adjustable Stay Roller
Our Offset/Adjustable Stay Roller is perfect for larger sliding doors up to 3-5/8” thick.
Can be mounted directly to the building side or the mounting bracket can be inverted and anchored into concrete.
Purchase
Long Face Mount Track Bracket
Our Offset/Adjustable Stay Roller is perfect for larger sliding doors up to 3-5/8” thick.
Can be mounted directly to the building side or the mounting bracket can be inverted and anchored into concrete.
Purchase
Short Face Mount Track Bracket
This Short Face Mount Brackets contain an integral rivet that interlocks into the keyhole slot.
Purchase
